Extremely thin and aesthetic design for the light body, make it have better visual experience than the traditional COB strip.
LINIO NEON EOS TV as verticalbending with radius of 10mm/0.39'' allows you using your design talents to your advantage. Dot-free itself, it is a perfect presentation of aesthetics and optics combination. IP65 protection with high performance silicone, UV resistant, solvents resistant. Perfect color consistency thanks to 3-Step LED in One BIN Only. 30m/reel(98.43ft/reel) maximum. And max. run length refers to single side feed in serial connection. It is easy to be cut and reconnected at project sites. Also, custom length is available as well.
| Voltage | DC24V(23.5Vmin 24.5Vmax) |
| LED PIN Temperature | Max. 65℃ /149°F |
| Storage Temperature | --25℃ /-13° F min , 60℃ /140 °F max |
| Min. Ambient Temperature (Ta min) | -25oC/-13oF |
| Max. Ambient Temperature (Ta max) | 55℃ /131° F@1.52W, 45℃ /113° F@10W |
| Power (W/m W/ft) | 5W/M, 10W/M Or 1.52W/FT, 3.05W/FT |
| Efficacy (lm/W) | 81lm/W@5W, 80lm/W@10W (4000K) |
| SDCM | 3 ( 2700K, 3000K, 4000K) |
| CRI | Ra90 |
| Cut Increments | 25mm/0.98" |
| Warranty | 5 Years |
For Beamever United States
| LM/FT | 1.52W/FT | 3.05W/FT |
| 2700K | 107 | 209 |
| 3000K | 116 | 229 |
| 3500K | 127 | 245 |
| 4000K | 124 | 244 |
| 5000K | 125 | 245 |
| 6500K | 126 | 246 |
| Max. run Length(FT) | 16.4FT | 16.4FT |
For Beamever International
| LM/M | 5W | 10W |
| 2700K | 351 | 686 |
| 3000K | 380 | 751 |
| 3500K | 417 | 804 |
| 4000K | 407 | 800 |
| 5000K | 410 | 804 |
| 6500K | 413 | 807 |
| Max. run Length(M) | 5M | 5M |
Features
Installation Benefits
With benefits of easy cut and reconnection, you could save much more time and labor cost at project sites. Besides, we also offer custom length service.
Accessories
Simple accessories also represent the ease of installation. Male and female connectors allow easier connections plug and play. Due to the slim and light body, it can be installed tightly with the small clips.
Protection
IP65 waterproof, anti-UV, anti-solvent, and all raw materials applied in to the product are green&healthy, All our products are certified by UL, CE, ROHS, REACH.
Application
Due to its dot-free and flexibility, EOS TV can be freely applied to various occasions, such as theatre, office, meeting room, villa, and other common places.
