Totally Designable, Twistable, and Appreciable as 3D-emitting
LINIO NEON 3D contributed as very beautiful top bend & side bend which perfectly combined into ONE for creating 3D space with radius of 100MM/3.94". Cross section size is 16mm x 15mm / 0.63" x 0.59" (W x H). Adopt the safe-power-supply as DC42V with 23.5 V min and 24.5 max. CRI Ra93, wide color temperature ranges to fit with different lighting needs@2700K to 5000K. Furthermore, IP67 with reasonable working temperature from -25oC to +45oC. Practical of lighting purposes such as architectural lighting, façade accent lighting, landscape lighting, etc. Always seek the matchless beauty and external qualities. And directly strives towards producing the flawless lighting quality.
| Voltage | DC24V(23.5Vmin 24.5Vmax) |
| LED PIN Temperature | Max 65oC/149oF |
| Storage Temperature | -25oC/-13oF min 60oC/140oF max |
| Min. Ambinet Temperature (Ta min) | -25oC/-13oF |
| Max. Ambient Temperature (Ta max) | 45oC/113oF@10W |
| Power (W/m, W/ft) | 10W/M; 3.1W/FT |
| CRI | Ra93 |
| Unit Cut | 50mm/1.97'' |
For Beamever United States
| LM/FT | 3.05W |
| 2700K | 211 |
| 3000K | 214 |
| 3500K | 217 |
| 4000K | 220 |
| 5000K | 224 |
| Max. Run Length (FT) | 16.4 |
For Beamever International
| LM/M | 10W |
| 2700K | 692 |
| 3000K | 703 |
| 3500K | 711 |
| 4000K | 720 |
| 5000K | 736 |
| Max. Run Length (M) | 5 |
Features
Unique designs
Include our LINIO NEON 3D is totally twistable, that allows you to bend it vertically or horizontally. Super creative and being extremely applicable for different projects. And each of the light, either the angle, the degree, or the lumen are coming from very careful consideration. Precisely of optical designing to ensure the high-quality of lighting & the permanent flawless. Being flexible and cuttable, to ensure diffused lights without any visible spots. And allows you to freely follow up those lighting-imagination.
Accessories
There are more options to support your different needs. For example, anodized aluminium channel specific for straight illumination, or the clips for curved or shaped places. And the male and female connectors allow easier connections plug and play. Also with full ranges of drivers provide the best service for you, e.g., apply the dimming and DALI control system for ON/OFF. And just in case you need to cut the product, and apply the Silicone glue to fix the end cap & closed end cap.
Full protection
Anti-chemical reactions, anti-UV, IP67waterproof, dust-free. Totally provide the best illuminance 24/7 for your project. And ensure the super durable working-performance in lighting-emitting.
Installation Benefits
With benefits of easy cut and reconnected at project sites. And the custom length are available as well. Plus the seamless cable entry makes perfect lighting line without any interruption. And here we have the most important method regarding front cable entry.
| Specification Sheet |
| Installation |
| LINIO NEON 3D Installation |
| IES |
| LINIO NEON 3D-930-10W_IESNA2002 |
| Brochure |
| LINIO NEON 3D Brochure |
