Precise and Exquisite of Design for Appearance & Lighting Angle
LINIO NEON 1220 SV RGBW for stunning side view, 4 in 1@RGB+W of 2700K to 5300K, present impressive color-effect. Within safe-power-supply of DC24V specific as 23.5V min & 24.5V max. Bending radius of horizontal bending is 120mm / 4.72". Cross section size 12mm x 20mm /0.47" x 0.79" (W x H). IP67 waterproof, works in temperature range from -25oC to +55oC. Applicable locations include commercial business offices, streets, shopping malls; residential areas such as international apartments, hotels, or Airbnb; decorating those aesthetic & various types of buildings.
| Voltage | DC24V(23.5Vmin 24.5Vmax) |
| LED PIN Temperature | Max 59.4oC/138.92oF |
| Storage Temperature | -25oC/-13oF min 60oC/140oF max |
| Ambient Temperature | Ta min=-25oC/-13oF, Ta max=35oC/95oF@15W |
| Ta max=55oC/131oF@3.75W (single color) | |
| Power (W/m, W/ft) | 15W/m ; 4.6W/ft |
| Efficacy (lm/W) | 32.8 |
For Beamever United States
| CCT | LM/ft | Max. Watt (W/ft) | Max. Run Length (ft) | Unit Cut (in) |
| R | 11 | 1.14 | 32.80 | 4.92 |
| G | 33 | 1.14 | 32.80 | 4.92 |
| B | 10 | 1.14 | 32.80 | 4.92 |
| W27 | 37 | 1.14 | 32.80 | 4.92 |
| W40 | 41 | 1.14 | 32.80 | 4.92 |
| W53 | 38 | 1.14 | 32.80 | 4.92 |
| RGBW40 | 95 | 4.57 | 32.80 | 4.92 |
For Beamever International
| CCT | LM/Mtr | Max. Watt (W/M) | Max. Run Length (m) | Unit Cut (mm) |
| R | 36 | 3.75 | 10 | 125 |
| G | 107 | 3.75 | 10 | 125 |
| B | 34 | 3.75 | 10 | 125 |
| W27 | 122 | 3.75 | 10 | 125 |
| W40 | 136 | 3.75 | 10 | 125 |
| W53 | 123 | 3.75 | 10 | 125 |
| RGBW40 | 313 | 15 | 10 | 125 |
Features
Installation Benefits
With benefits of easy cut and reconnected at project sites. And the custom length are available as well. Plus the seamless cable entry with different directions makes perfect lighting line without any interruption. And here we have three approaches regarding front cable entry, side cable entry, and bottom cable entry.
Accessories
There are more options to support your different needs. For example, anodized aluminium channel specific for straight illumination, or the clips for curved or shaped places. And the male and female connectors allow easier connections plug and play. Also with full ranges of drivers provide the best service for you, e.g., apply the dimming and DALI control system for ON/OFF. Or apply the RGBW controller for remote & colorful control
Control System
As the DMX512, plus the DMX decoders to manipulate and ensure excellent-performance among devices, lights, and systems, e.g., to display more vivid and impressive lighting showcase.
Options
Providing thousands of coloring-options, and the feature of being flexible & cuttable which all benefits for you to create more artistic, and free the space for inspiration.
Protection
IP67 as great protection from series of water in-breaking, e.g., rain, fog, or vapor. Perfectly works for both external and internal lighting-emitting.
