With Beautiful Side View, and Horizontal Bending to Provide Homogeneous Outcome
LINIO NEON 1220 SV as the side view, and it’s horizontal bending with radius of 120mm / 4.72". Plus the dimension of cross section size is 12mm x 20mm / 0.47" x 0.79" (W x H). Adopt the safe-power-supply within DC24V with specific of 23.5V as min, and 24.5V as the max. Furthermore, it stays ONE BIN ONLY of color-consistency principle. With WHT range from 2700K to 6500K@CRI Ra94. Available working temperature range from -25oC to +55oC. With IP67 waterproof and other trustful systems coordination, make LINIO NEON 1220 SV can achieve stunning lighting effects, effectively and elegantly highlighting certain areas in architectural lighting projects and tracing straight, curved and even round contours with homogeneous lighting.
| Voltage | DC24V(23.5Vmin 24.5Vmax) |
| LED PIN Temperature | Max 59.4oC/138.92oF |
| Storage Temperature | -25oC/-13oF min 60oC/140oF max |
| Min. Ambient Temperature (Ta min) | -25oC/-13oF |
| Max. Ambient Temperature (Ta max) | 55oC/131oF@5W, 45oC/113oF@10W, 35oC/95oF@15W |
| Power (W/m W/ft) | 5, 10, 15W/m ; 1.52, 3.05, 4.57W/ft |
| CRI | Ra94 |
| Unit Cut | 50mm / 1.97" |
For Beamever United States
| LM/ft | 1.52W | 3.05W | 4.57W |
| 2700K | 45 | 99 | 133 |
| 3000K | 48 | 105 | 150 |
| 3500K | 49 | 108 | 152 |
| 4000K | 46 | 105 | 145 |
| 5300K | 47 | 106 | 149 |
| Max. Run Length (ft) | 88.56 | 55.76 | 45.92 |
For Beamever International
| LM/M | 5W | 10W | 15W |
| 2700K | 146 | 324 | 436 |
| 3000K | 156 | 346 | 492 |
| 3500K | 160 | 355 | 500 |
| 4000K | 150 | 346 | 475 |
| 5300K | 155 | 349 | 490 |
| Max. Run Length (M) | 27 | 17 | 14 |
Features
Accessories
There are more options to support your different needs. For example, anodized aluminium channel specific for straight illumination, or the clips for curved or shaped places. And the male and female connectors allow easier connections plug and play. Also with full ranges of drivers provide the best service for you.
Application
It is an ideal option & practical for architectural lighting, facade accent lighting, landscape lighting, and with other applications. Totally just to light up and beautify each of your projects by creating stylish lighting effects. Plus with excellent flexibility and cuttability leaves you free to follow up your light inspiration and create all kinds of shaped lighting with ease.
Installation Benefits
The single side feed of Max. Run length is up to 27 meters. With benefits of easy cut and reconnected at project sites. And the custom length are available as well. Plus the seamless cable entry with different directions makes perfect lighting line without any interruption. And here we have three approaches regarding front cable entry, side cable entry, and bottom cable entry.
Protection
As IP67 waterproof, UV resistant, solvents resistant, and being extremely durability and flexibility thanks to high performance materials.
