LINIO NEON 1220 SV

With Beautiful Side View, and Horizontal Bending to Provide Homogeneous Outcome


LINIO NEON 1220 SV as the side view, and it’s horizontal bending with radius of 120mm / 4.72". Plus the dimension of cross section size is 12mm x 20mm /0.47" x 0.79" (W x H). Adopt the safe-power-supply within DC24V with specific of 23.5V as min, and 24.5V as the max. Furthermore, it stays ONE BIN ONLY of color-consistency principle. With WHT range from 2700K to 6500K@CRI Ra94. Available working temperature range from -25oC to +55oC. With IP67 waterproof and other trustful systems coordination, make LINIO NEON 1220 SV can achieve stunning lighting effects, effectively and elegantly highlighting certain areas in architectural lighting projects and tracing straight, curved and even round contours with homogeneous lighting.

VIEW
LINIO NEON 1220 SV TW

Bring Homogeneous Lighting to Your Both Interior and Exterior Projects


LINIO NEON 1220 SV TW adopt the safe-power-supplying within DC24V as 23.5V of the min, & 24.5V of the max. Dimension pf cross section size with 12mm x 20mm /0.47" x 0.79" (W x H), plus the radius of horizontal bending is 120mm / 4.72". LINIO NEON 1220 SV TW could be very good at to deal with various hash-environments, and perfectly work from -25oC to +45oC. With IP67 waterproof which perfect solve the indoor and outdoor lighting-decorations. Such as works a tracing straight, curved, or as the round contours with even lighting.

VIEW
LINIO NEON 1220 SV RGB

Open up Many Colors Possibilities through Red-Green-Blue Color Mixing


LINIO NEON 1220 SV RGB ensure the safe-power-supply as DC24V specific of 23.5V min, & 24.5V max. Stay ONE BIN ONLY color consistency, and provides homogeneous light effect be display 24/7. Dimension of side view, and the radius of horizontal bending is 120mm / 4.72". Plus the cross section size is 12mm x 20mm /0.47" x 0.79" (W x H). However, the working temperature from -25oC to +50oC, with IP67 as the important feature of solving outside & inside lighting-decorations. For example, commercial business offices, residential areas as personal mansions, or architectural decorations.

VIEW
LINIO NEON 1220 SV RGBW

Precise and Exquisite of Design for Appearance & Lighting Angle


LINIO NEON 1220 SV RGBW as very beautiful side view, 4 in 1@RGB+W of 2700K to 5300K, and present impressive coloring-effect. Within safe-power-supply of DC24V specific as 23.5V min, & 24.5V max. Dimensions of radius of horizontal bending is 120mm / 4.72". And the cross section size 12mm x 20mm /0.47" x 0.79" (W x H). IP67 waterproof, and works in temperature range from -25oC to +55oC. Applicable locations as commercial business offices, streets, shopping malls; residential areas such as international apartments, hotels, or Airbnb; and to decorate those aesthetic & various shaped of buildings.

VIEW
LINIO NEON 1220 SV PIXEL RGBW

Great Features of Flexible, Cuttable, and Custom Length as Optional


LINIO NEON 1220 SV PIXEL RGBW contributed as very exquisite side view emitting, horizontal bending with radius of 120mm / 4.72". And the cross section size 12mm x 20mm /0.47" x 0.79" (W x H). And the power-supply range as DC24V, range from 23.5V min to 24.5V max. IP67 waterproof, WHT range from 2700K to 5300K, plus working temperature from -25oC to +55oC. Furthermore, DMX512 control system to operate the devices, lights, and systems maintaining a very stable and dependable performance. Plus to offer very amazing effects, such as chasing, rain, or coloring-changes of various effects. Very eye-catching, dynamic, and extremely magnificent.

VIEW
LINIO NEON 1225 SV

As the Specialist of WHT Color Only, Precisely & Professionally


LINIO NEON 1225 SV as very impressive side-view emitting, horizontal bending with radius of 75mm / 2.95", and the cross section size is 12mm x 25mm /0.47" x 0.98" (W x H). DC24V of 23.5Vmin & 24.5Vmax as the range of safe-power-supplying. As IP67 waterproof, plus the working temperature range from -25oC to +55oC. And lighting as the dome-shape side version neon which can effectively and elegantly to highlight any certain of areas in architectural lighting projects. Fit with various angles and shapes, such as the trace-straight, curved, or round-contour. Maintain very high color-consistency cause to follow up the ONE BIN ONLY principle.

VIEW
